Rated Torque – 160Nm (S3 40%)
Max Load in 2:1 – 1.000kg (120mm traction sheave)
Car speed – 0,15 … 1m/s
Power Range – 1 … 5,4 kW
Traction Sheaves – 120 … 210mm
Max Static Load – 19,6 kN – 2.000kg
Max Width – 232mm (without hand release) – 249mm (with hand release)
Braking Torque – 2x180Nm
Max Weight – 104kg
