Rated Torque – without fan 250Nm (S3 40%)
with fan 290Nm (S3 40%)
Max Load in 2:1 – 1600kg (puleggia da 120mm)
Car speed – 0,63 … 2m/s
Power Range – 3,1 … 8,8 kW
Traction Sheaves – 120 … 320mm
Max Static Load – 34,3 kN – 3.500kg
Max Width – 290mm
Braking Torque – 2x280Nm
Max Weight – 163kg
