Rated Torque – 90Nm (S3 40%)
Max Load in in 2:1 – 480kg (puleggia da 120mm)
Car speed – 0,15 … 1m/s
Power Range – 0,6 … 2,9 kW
Traction Sheaves – 120 … 210mm
Max Static Load – 19,6 kN – 2.000kg
Max Width – 232mm (without hand release) – 249mm (with hand release)
Braking Torque – 2x180Nm
Max Weight – 95kg
DownloadRated Torque – 90Nm (S3 40%)
Max Load in in 2:1 – 480kg (puleggia da 120mm)
Car speed – 0,15 … 1m/s
Power Range – 0,6 … 2,9 kW
Traction Sheaves – 120 … 210mm
Max Static Load – 19,6 kN – 2.000kg
Max Width – 232mm (without hand release) – 249mm (with hand release)
Braking Torque – 2x180Nm
Max Weight – 95kg
